444C Series
444 C
|
MODEL
|
RIVET
CAPACITY DIAMETER |
STANDARD
YOKE DIMENSIONS |
MAX FORCE with 90 PSI (6.21 BAR) AIR PRESSURE PSI (KN) |
OVERALL LENGTH |
MAX
RAM TRAVEL |
STROKE AT MAX POWER |
WEIGHT LBS (kgs) |
||
|
ALUM
|
STEEL
|
REACH
|
GAP
|
With Yoke
|
|||||
| 444C21 | 5/16 (7.9) |
1/4 (6.35) |
2-1/8" (53.97) |
1-1/2" (38.1) |
14,000 (62.3) |
26" (660.4) |
5/8 (19.05) |
3/32 (2.38) |
15" (6.8) |
| 444C1518 | 5/16 (7.9) |
1/4 (6.35) |
3" (76.2) |
1-1/2" (38.1) |
14,000 (62.3) |
26" (660.4) |
5/8 (19.05) |
3/32 (2.38) |
15" (6.8) |
*All pressures are load cell tested not calculated.
